PS36
Description:
Agrade mSATA SSD is the storage device based on NAND flash memory technology. This product complies with Serial ATA standard interface and suitable for data storage media and code storage device for embedded system and boot disk. By using mSATA SSD Module, it is possible to operate good performance for the systems, which have SATA interface. With small form factor, the applicable appliance can add or install SATA storage device on its Mother Board or Complete set.
Application Fields:
- Netbook, mini PC, mobile PC.，of medical，automate，POS，gaming machine，military,traffic,Energy，Monitor，AD player，Bank.
- Other machines and Equipments with Serial ATA Interface.
Features:
- MO-300A Standard
- P/E：SLC(60000) MLC(3000)
- SATAIII 6.0Gb/S
- Advanced Wear Leveling and Error Checking and Correction
- Support S.M.A.R.T
- Intelligent destruction function
Description
| Product Name | Industrial mSATA SSD |
| Series | Hi-Speed Series |
| Model Name | PS36 |
| Capacity | SLC：4GB~32GB
MLC：4GB~512GB |
| Feature
|
MO-300A Standard |
| P/E：SLC(60000) MLC(3000) | |
| SATAIII 6.0Gb/S | |
| Advanced Wear Leveling and Error Checking and Correction | |
| Support S.M.A.R.T | |
| Intelligent destruction function | |
| Shock / Vibration | 1500/20 |
| MTBF(h) | 2,000,000 |
| Operating Voltage | 3.3 V |
| Operating Temperature | NT：0℃ ~ 70 ℃ WT：-40 ℃~85 ℃ |
| Storage Temperature | -55℃ ~95℃ |
| Sequential R/W Performance(Max) | Read：530MB/S Write：300MB/S |
| Dimension(LxWxH) | 50.95mm(L)X30mm(W)x3.9mm(H) |
